Description
RAB WFR34-4B/BP 4 in. Baffle Downlight — 9W / Selectable CCT
The RAB WFR34-4B/BP is a 4-inch baffle trim downlight delivering 631 lumens using 9W. This energy-efficient fixture offers selectable color temperatures ranging from 2700K to 5000K, making it perfect for various lighting needs. Designed for easy installation, it features a canless design with a pre-wired junction box.
Key Features
- Wattage: 9W
- Lumens: 631 lm
- Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
- Voltage: 120V
- Dimming: TRIAC/ELV dimming down to 10%
- Beam Angle: 110°±10°
- CRI: 90
- Lifespan: 30,000 hours
- Compliance: Title 24 JA8, RoHS, FCC
- Environment: Wet rated
Construction & Aesthetics
The downlight features a white baffle trim and a frosted polycarbonate lens for even light distribution. It is constructed from durable plastic and metal materials, ensuring longevity and reliability. Compatible accessories include color trim rings and goof rings for aesthetic customization.
Electrical & Installation
Designed for 120V systems, this fixture supports TRIAC/ELV dimming. It includes a remote driver with a built-in junction box, eliminating the need for traditional housings. Accessories such as mounting plates and nailer bars are available for enhanced installation flexibility.
Light Output & Performance
With a lumen output of 631 and a high CRI of 90, this downlight ensures excellent color rendering and brightness. The wide beam angle of 110°±10° provides ample coverage for general lighting applications.
Typical Applications
- Residential lighting
- Commercial spaces
- Bathrooms
- Outdoor covered areas
- Hallways
