RAB RBAY17M Field-Adjustable Linear LED High Bay — 260W / 220W / 160W Selectable
The RAB RBAY17M is a field-adjustable linear LED high bay delivering up to 39,200 lumens with selectable wattage options of 260W, 220W, and 160W and selectable CCT of 3500K / 4000K / 5000K. The fixture operates on 120–277V with integrated 0–10V dimming to 10%. It is UL Listed for damp locations and is DLC Premium Listed for rebate eligibility. Designed for warehouses, distribution centers, manufacturing facilities, retail stockrooms, and other commercial or industrial environments requiring adaptable linear illumination.
Key Features
- Selectable Wattage: 260W / 220W / 160W
- Selectable CCT: 3500K / 4000K / 5000K
- Maximum Output: Up to 39,200 lumens
- Voltage Range: 120–277V, 50/60Hz
- Dimming: 0–10V dimming to 10%
- Environmental Rating: UL Listed for damp locations
- Certifications: UL Listed; DLC Premium Listed
- Rated Life: 100,000 hours (L70)
Typical Applications
- Warehouses
- Distribution centers
- Manufacturing facilities
- Retail stockrooms
- Industrial workshops
- Gymnasiums
- Storage areas
Performance & Light Output:
Delivered lumen output depends on selected wattage and CCT. Efficacy typically ranges above 144 lm/W with CRI 81–84. Rated life is 100,000 hours (L70) based on independent LED testing standards.
Electrical & Controls:
Operates on 120–277V, 50/60Hz with a constant current driver. Integrated 0–10V dimming capable down to 10%. Surge protection rated for typical industrial environments.
Construction & Durability:
Die-cast aluminum housing with polycarbonate lens. Suitable for damp locations with robust commercial construction. Mercury-free and RoHS-compliant components.
Installation & Mounting:
Includes V-hooks and chain for suspension mounting. Optional surface and pendant mounting kits available separately. Sensor-ready port compatible with RAB PIR and microwave sensors.
Included
LED linear high bay fixture, V-hooks, and chain.
