American Lighting Trulux COB LED Tape Light — 4000K & Seamless Design
The HTL-COB-WH-16 is a high-performance COB LED Tape Light from American Lighting’s Trulux series. This 16.4ft tape light operates at 24V DC and is IP54 rated, making it suitable for damp locations. It features a seamless design that eliminates LED dotting, providing uniform illumination ideal for areas with low clearance or reflective surfaces.
Key Features
- Voltage: 24V DC for consistent power delivery.
- Wattage: Consumes 4.5 watts per foot.
- Lumens: Up to 460 lumens per foot for bright, effective lighting.
- LEDs per Foot: Seamless COB design for dotless illumination.
- Maximum Run: 16.4 feet to prevent voltage drop.
- Cuttable Increments: Every 1.97 inches for precise customization.
- PCB Width: 10mm, compatible with various mounting channels.
- Beam Angle: 120 degrees for wide light distribution.
- IP Rating: IP54, suitable for indoor damp locations.
- Certifications: cULus Listed, JA8 Compliant.
Core Design & Construction
The tape light features a 10mm wide PCB, ensuring compatibility with most aluminum channels. It includes a light nano-coating for protection against moisture and dust, and a 3M VHB adhesive backing for secure installation.
LED Illumination & Performance
With up to 460 lumens per foot and a 90+ CRI, this COB LED tape light provides high-quality illumination. The seamless design ensures a continuous line of light without visible diodes.
Power, Wiring & Installation
This tape light requires a 24V DC power supply and is dimmable with most ELV and TRIAC dimmers. It can be cut every 1.97 inches and supports a maximum run of 16.4 feet to prevent voltage drop.
Where This Tape Works Best
- Cove lighting
- Under cabinet lighting
- Accent lighting
- Retail displays
- Architectural features
What’s Included
- 16.4ft reel
- 6ft lead and tail
- (1) TL-CONKIT
- (2) TL-BLKS
- (2) TL-2PWR-HD
